Valleylab Force FX FX-8C Electrosurgical Generator Machine Power Supply Board/RF board 02-32380-0071

Valleylab Force FX-8C Generator Power Supply/RF board

Valleylab Force FX FX-8C Electrosurgical Generator Machine Power Supply Board/RF board 02-32380-0071

► Brief Description

Valleylab Force FX-8C Generator Power Supply/RF board 02-32380-0071 - It is the most important board on this device, it mainly contains the high voltage power supply and RF output stage. There are many executive circuits including output voltage monitoring, output current monitoring, leakage current detection (RF leakage current detection and reduction circuit), spark control circuit, REM impedance monitoring (REM circuit), manual switch closure detection (IsoBloc circuit), RS- 232 connector, expansion connector, EKG contact closure connector, output high voltage relay and temperature monitoring and fan control.

► Specification

► More Details

Remove low voltage power supply

1. Turn off the power;

2. Unscrew the five screws that secure the cover to the chassis, and lift the cover away from the chassis;

3. Unscrew the three screws securing the bracket to the radiator;

4.Disconnect and remove the low voltage power supply.
